Independence High Bay

IHB

The Independence Series High Bays offer exceptional performance and value in a lightweight, compact design. Available in single, double and triple module configurations and are perfect for virtually any high bay application. A portion of the proceeds from every Independence Series product sold will be donated to The Independence Fund, a non-profit organization dedicated to helping wounded veterans.

Ask a Question

Variations

HousingUnitLensCRI4000K CCT4500K CCT5000K CCTWattageReplaces Up To
Delivered LumensEfficacy (LpW)Delivered LumensEfficacy (LpW)Delivered LumensEfficacy (LpW)
IHB12LClear8012,52815212,52815912,59716083175W MH
12LDDiffused8011,35813811,35813811,42113982
12LNNarrow8011,08914311,08914311,50114579
15LClear8016,14415416,14415216,513157105250W MH
15LDDiffused8014,56714014,56714014,949143105
15LNNarrow8014,65214014,65214015,196145105
18LClear8018,59715318,59715319,022156122250W MH
18LDDiffused8016,76713716,76713717,207141122
18LNNarrow8016,76613816,76613817,389143122
24LClear8023,91014823,89914823,899148162400W MH
24LDDiffused8021,50613321,40413621,404136162
24LNNarrow8021,36313221,36313221,491133162
30LClear8029,55015929,55015930,370166186400W MH
30LDDiffused8026,47014326,47014327,343149185
30LNNarrow8026,48814326,48814327,097148185

Features & Specifications

  • The high brightness LEDs produce a smooth, even and uniform light pattern at a variety of mounting heights.
  • Clear lens is standard; also available with a diffused lens for enhanced visual comfort, and narrow optics for aisle lighting applications.
  • The low-profile housing is lightweight and durable, making it easy to install and perfect for many applications.
  • The convenient quick wire access panel is easy to open by removing a single screw on the top of the fixture.
  • The tool-free driver compartment allows for easy access for maintenance.
  • The available Pendant Mount Kit makes 1‑to‑1 HID replacements quick and easy.
  • Also available in double and triple module configurations to accommodate an even larger array of high bay applications.
Max Lumens
30,000
Min Lumens
12,000
Color Temperatures
4000K 4500K 5000K
Additional Options
QuickShipDLCUS Manufactured (BAA Compliant)DimmableUL ListedBattery Backup
