Origin High Bay
Origin by Atlas Lighting is our economy line of products that are designed to provide a highly competitive, lower-cost entry point to LED lighting. The Origin lineup of Linear High Bays offers a range of lumen packages and configurations to meet a variety of different high bay applications.
All Available Sizes
Featured Resources
Variations
| Housing | Unit | CRI | 4000K CCT | 5000K CCT | Wattage | Replaces Up To | ||
| Delivered Lumens | Efficacy (LpW) | Delivered Lumens | Efficacy (LpW) | |||||
| ORHB | 12L | 80 | 12,534 | 133 | 12,507 | 133 | 94 | 175W MH |
| 18L | 80 | 17,170 | 133 | 17,049 | 132 | 129 | 250W MH | |
| 24L | 80 | 21,171 | 126 | 23,111 | 138 | 168 | 400W MH | |
Features & Specifications
- Energy-efficient design saves money on energy costs.
- High brightness LEDs and diffused lens create a smooth light distribution pattern.
- Origin products are backed by the same US-based customer service and technical support teams as all other Atlas products.
- Product series is available in 2 different housing sizes.
Max Lumens
23,000Min Lumens
12,500Color Temperatures
4000K 5000KAdditional Options
