Fully Selectable Area Light Medium

ORASEL30-43L

The Fully Selectable Area Lights are fully customizable with selectable lumens and color temperature, which reduces stocking complexity and provides additional flexibility for contractors. The included Multi-Mount Bracket enables round pole, square pole and slipfitter mounting. Changing distribution patterns is a snap with the Snap-Tight Magnetic System, with Type III pre-installed and Type V & FT (T4) included in the carton.

All Available Sizes

Small

ORIGIN SERIES FULLY SELECTABLE AREA LIGHT MEDIUM (ORASEL30-43L)

Featured Resources

ORASEL Cut Sheet

Ask a Question

Variations

Housing	Lumen Package	Distribution	CRI	3000K CCT		4000K CCT		5000K CCT		Wattage	Replaces Up To
Housing	Lumen Package	Distribution	CRI	Delivered Lumens	Efficacy (LpW)	Delivered Lumens	Efficacy (LpW)	Delivered Lumens	Efficacy (LpW)	Wattage	Replaces Up To
ORASEL	30-43L	T3	80	30,197	148	31,993	161	32,486	159	200	400W
		T4 (FT)		30,927	149	32,721	162	32,927	159
		T5		30,514	152	32,318	164	32,996	163
		T3		35,331	143	37,689	157	38,238	154	240	1000W
		T4 (FT)		35,024	145	37,661	159	37,141	153
		T5		35,439	148	37,746	161	38,414	158
		T3		41,560	138	44,839	154	45,503	151	300	1000W
		T4 (FT)		41,283	138	45,261	159	44,205	147
		T5		43,145	143	45,695	157	46,111	152

Features & Specifications

Features multiple selectable lumen packages and color temperatures in a single fixture.
Included Multi-Mount Bracket enables round pole, square pole and slipfitter mounting.
Offers 180º of mounting angle adjustment.
Snap-Tight Magnetic System makes changing the optics easy.
Type III pre-installed, Type V & FT (T4) included in the carton.
Photocontrol and Shorting Cap are included.
Durable, die-cast aluminum construction ensures fixture longevity.
10kV/10kA External Surge Protection Standard
